Q: Ink flow

Reasons 1、It becomes easy to flow ink where has powder impurities or crush wounds 2、The heating board is not open after printing Solutions If the ink flow is due to the poor absorption, we can try 1, reduce the proportion of white ink setting, appropriate to reduce the amount of white ink 2, increase the temperature of the printer heating board can also improve the pass rate 3, board heating can help ink activation and then reduce ink flow phenomenon

Q: Blurred pattern

Reasons The nozzle is clogged/the height is improper, resulting in uneven ink, low driver/unstable or fast printing speed, the ink is not dried and fixed in time. Solutions 1. The nozzle is clogged or the height is improperly set, resulting in uneven ink distribution. 2. The printer driver version is low or unstable. 3. The printing speed is too fast, and the ink is difficult to dry and fix in time.

Q: oily or damp

Reasons Baking dried patterns or pasted and transferred patterns become oily and damp Solutions It belongs to the phenomenon that the glue is not baked thoroughly, the water and glycerin in the ink cannot be thoroughly baked and then reversed. Generally speaking, single sheet operating version with 120 degrees low temperature for a long time through it best. As powder is limited by the length of the powder machine, so we can try to raise the connected board appropriate high temperature to make the water and glycerin evaporation in advance might also help

Q: Flaking powder

Reasons The blank place powder around the pattern sticks the coating after heat transfer printing Solutions May due to the heat transfer printing pressure is too high, which makes the film ink absorbing layer damage peeling or fabric surface size easy to stick the coating. Generally, as long as the temperature and pressing time can meet the requirements of sticking firmly, it can be easily solved when adjust the pressure as small as possible down

Q: Printing ink bleeding

Reasons Printing ink bleed is caused by uneven surface coating, poor ink compatibility or excessive flow, and the ink is not effectively fixed. Solutions 1.Choose DTF PET Film with good and uniform coating quality. 2.Use matching special ink. 3.Adjust the ink flow rate to reduce and test the best parameters.

Q: Ink flow

Reasons 1、It becomes easy to flow ink where has powder impurities or crush wounds 2、The heating board is not open after printing Solutions If the ink flow is due to the poor absorption, we can try 1, reduce the proportion of white ink setting, appropriate to reduce the amount of white ink 2, increase the temperature of the printer heating board can also improve the pass rate 3, board heating can help ink activation and then reduce ink flow phenomenon

Q: Powder shaken unclear

Reasons Wet weather, humidity, strong static electricity, it needs to check when the edge of the pattern is unclean. 1、 Whether high humidity or low temperature 2、Whether the strength of powder shaking machine is insufficient 3、Whether the printing interval is too long without powder caused by drying glycerin diffusion 4、 Whether ink misting on heads Solutions If it is found that the pressure wheel position or large blank area shaking is not clean, it should be electrostatic influence or powder damp or too fine, you can take measures as appropriate. Generally, increasing the temperature of the heating board after printing and shake powder machine connected board can reduce the edge powder shaken unclear.

Q: Powder holes

Reasons Ink water and glycerin boiling evaporation with high temperature and short time baking dried, which pulls holes out of the coating and film Solutions It' better to give priority to medium and fine powder, a little coarse powder or even no coarse powder, it works best when baking dried in the low and high temperature section for a long time, it works best when baking dried in the low and high temperature section for a long time, it can be gradual to dry oil and water and melt glue thoroughly, but no violent reaction. The resulting film is flexible, elastic, smooth and dry. If the powder machine begins with a slightly poor conditions, it's necessary to make use of the function of preheating chopping board to heat and steam away some water in advance to reduce the burden, dry them then shake powder.

Question 1

Ink flow

Accepted Answer

Reasons

1、It becomes easy to flow ink where has powder impurities or crush wounds 2、The heating board is not open after printing

Solutions

If the ink flow is due to the poor absorption, we can try 1, reduce the proportion of white ink setting, appropriate to reduce the amount of white ink 2, increase the temperature of the printer heating board can also improve the pass rate 3, board heating can help ink activation and then reduce ink flow phenomenon

Question 2

Blurred pattern

Accepted Answer

Reasons

The nozzle is clogged/the height is improper, resulting in uneven ink, low driver/unstable or fast printing speed, the ink is not dried and fixed in time.

Solutions

1. The nozzle is clogged or the height is improperly set, resulting in uneven ink distribution.

2. The printer driver version is low or unstable.

3. The printing speed is too fast, and the ink is difficult to dry and fix in time.

Question 3

oily or damp

Accepted Answer

Reasons

Baking dried patterns or pasted and transferred patterns become oily and damp

Solutions

It belongs to the phenomenon that the glue is not baked thoroughly, the water and glycerin in the ink cannot be thoroughly baked and then reversed. Generally speaking, single sheet operating version with 120 degrees low temperature for a long time through it best. As powder is limited by the length of the powder machine, so we can try to raise the connected board appropriate high temperature to make the water and glycerin evaporation in advance might also help

Question 4

Flaking powder

Accepted Answer

Reasons

The blank place powder around the pattern sticks the coating after heat transfer printing

Solutions

May due to the heat transfer printing pressure is too high, which makes the film ink absorbing layer damage peeling or fabric surface size easy to stick the coating. Generally, as long as the temperature and pressing time can meet the requirements of sticking firmly, it can be easily solved when adjust the pressure as small as possible down

Question 5

Printing ink bleeding

Accepted Answer

Reasons

Printing ink bleed is caused by uneven surface coating, poor ink compatibility or excessive flow, and the ink is not effectively fixed.

Solutions

1.Choose DTF PET Film with good and uniform coating quality.

2.Use matching special ink.

3.Adjust the ink flow rate to reduce and test the best parameters.

Question 6

Ink flow

Accepted Answer

Reasons

1、It becomes easy to flow ink where has powder impurities or crush wounds 2、The heating board is not open after printing

Solutions

If the ink flow is due to the poor absorption, we can try 1, reduce the proportion of white ink setting, appropriate to reduce the amount of white ink 2, increase the temperature of the printer heating board can also improve the pass rate 3, board heating can help ink activation and then reduce ink flow phenomenon

Question 7

Powder shaken unclear

Accepted Answer

Reasons

Wet weather, humidity, strong static electricity, it needs to check when the edge of the pattern is unclean.

1、 Whether high humidity or low temperature

2、Whether the strength of powder shaking machine is insufficient

3、Whether the printing interval is too long without powder caused by drying glycerin diffusion

4、 Whether ink misting on heads

Solutions

If it is found that the pressure wheel position or large blank area shaking is not clean, it should be electrostatic influence or powder damp or too fine, you can take measures as appropriate.

Generally, increasing the temperature of the heating board after printing and shake powder machine connected board can reduce the edge powder shaken unclear.

Question 8

Powder holes

Accepted Answer

Reasons

Ink water and glycerin boiling evaporation with high temperature and short time baking dried, which pulls holes out of the coating and film

Solutions

It' better to give priority to medium and fine powder, a little coarse powder or even no coarse powder, it works best when baking dried in the low and high temperature section for a long time, it works best when baking dried in the low and high temperature section for a long time, it can be gradual to dry oil and water and melt glue thoroughly, but no violent reaction. The resulting film is flexible, elastic, smooth and dry. If the powder machine begins with a slightly poor conditions, it's necessary to make use of the function of preheating chopping board to heat and steam away some water in advance to reduce the burden, dry them then shake powder.
